Simple react grid component to handle your grid needs
With the increase of card designs inside websites, there is a huge need for grids either on a multiple level of a website or something as simple as showing an image beside text.
Why does this have to be so painful?
Supporting two sections is fine, but then mobile, then tablet. Then you need to support super large website now. Oh look my content looks like crap now. My image is stretched way more than it should have been, can't use per screenshot image sources. And now my design for opportune website of 1200px looks bad on anything smaller or bigger than that.
Introducing Grid Matrix!
A simple react grid component to handle your grid needs, some key features are:
- Allow alignment to center, top, bottom, left or right, or use our more intense support of
center-top|middle-top|left-top|right-top|center-middle|middle-middle|left-middle|right-middle|center-center|middle-center|left-center|right-center|center-bottom|middle-bottom|left-bottom|right-bottom
or specify your xAlign and yAlign levels for your own overrides
-
Support per screenshot breakdown views, specify how your medium (<768px) breakdown will show differently than your xxxl screensize (>1536px)
-
StackedGrid, stacking content is a pain, thats why out of the box you can stackGridonGridonGrid
and many other cool features...
- Node Version: 16
- Typescript (5.2.2 or higher)
We have storybook set up in this repo, so to run it locally, please run
npm install
** Note, you may need --force
then run
npm run storybook
This should open your primary website to localhost:6006 so that you can interact with the various pieces of Grid Matrix
When using <Grid /> you will need to wrap the component with a width and height, almost like a containment field for the grid component.
Description: Grid of content aligned in your perferred way
Example:
<Grid
sections: GridSectionProps[]
/>
Description: Stacking multiple Grid of information all in one place
Example:
<StackedGrid
grids: GridWithLevelRequiredProps[]
/>
There is a lot of features inside this package, but some of the key ones that make this helper component are:
Description: Allows you to specify where you section will be placed inside the Grid component.
Props inside GridSectionProps
align - Allow you to specify where your item is places inside the Grid,
ex1. center-center will place the section in the middle middle
ex2. center-bottom will place the section in the center but at the bottom
You can also use them separate:
xAlign - Allows you to specify the x-axis alignment of section
yAlign - Allows you to specify the x-axis alignment of section
ex1.
xAlign: 'left'
yAlign: 'top'
// will display the left side at the top of the Grid component
Description: You can pass in individual breakdowns for screensizes to the Grid component
Props inside GridSectionProps
xsSection, smSection, mdSection, lgSection, xlSection, xxlSection, xxxlSection
They all take in GridSectionProps[] which is just the standard sections prop for the Grid component, but if specified it will render this unique per page size
🎁 oh and don't worry, we rerender it ourselves if people increase or descrease the screen
Description: Sometimes when using margin and padding it sometimes breaks your UI, so we decided to allow a Spacer type, if you send in GridSectionProps without a content it will treat it like a Spacer
Example:
// ... another 40% cover section
{
cover: 20,
align: 'bottom'
}
// ... another 40% cover section
This will separate the two sides with a 20% Spacer
Description: Now we know sometimes packages restrict your abilities to create slight changes you need, so we have opened up allowing you to also add custom classes or styles
(This is supported in both the StackedGrid or Grid components)
Props inside GridProps
className : Custom class name for additional styling
styles : Inline styles for additional styling
transform : Support the CSS transform property on the top component. This can be a combination of rotation, scaling, translating, skewing, and more.
- Migrate from deprecated ComponentStory, ComponentMeta
- Update storybook examples with images
- Support containment field inside
<Grid>directly - Accessibility labels (and the ability to hide specific sections from readers)
