Angular Datatable SM

Dynamic Datatable SM generation based on your requirement i.e. Table heading with number of columns & its table data.

Installation

npm i angular-datatable-sm

Usage

Import

Step 1:

import { AngularDatatableSmModule } from 'angular-datatable-sm';

@NgModule({
  ...
  imports: [
    ...
    AngularDatatableSmModule
  ],
  ...
})

Step 2:

Create a service file in your project & copy the template provided for your project - table-data.service
or with mock JSON available below: Service File with JSON

ng generate service services/tableData/table-data

& import it inside component where you want to use our "angular-datatable-sm" package:

import { TableDataService } from './services/tableData/table-data.service';

constructor(public tableDataService: TableDataService) { }

make sure "public tableDataService: TableDataService" must be public to pass to package.

Fundamental Usage

Step 3:

Add in same component html file, where you have imported "TableDataService":

<lib-angular-datatable-sm
  [pagination]="true"
  [itemsPerPage]="5"
  [tableDataService]="tableDataService">    <!-- Passing Service you have created-->
</lib-angular-datatable-sm>

Fundamentals

Property/Method	Type	Default	Description
pagination	boolean	false	Parent flag to showcase pagination for data table
itemsPerPage	number	10	Mandatory field with "pagination" to show number of items per page
tableDataService	service	-	Service file having api calling methods & return observale which can subscribe further

Configuration - JSON/Object

Step 4:

Values with dummy data is mentioned below, to recieve as required response: Service file methods must return below format as response, to pass & "angular-datatable-sm" to work properly

let tableData = {
  data: {
    headers: [
      { id: 1, name: 'id', checked: true },
      { id: 2, name: 'name', checked: true },
      { id: 3, name: 'age', checked: false },
      { id: 4, name: 'email', checked: true },
      { id: 4, name: 'progress', checked: true },
      { id: 4, name: 'emp_number', checked: false },
      { id: 4, name: 'ratings', checked: false },
    ],
    entries: [
      { id: 1, name: 'John Doe', age: 30, email: 'john@example.com', progress: 10, emp_number: '245', ratings: 4.5 },
      { id: 2, name: 'Jane Doe', age: 28, email: 'jane@example.com', progress: 50, emp_number: '246', ratings: 4 },
      { id: 3, name: 'Michael Smith', age: 35, email: 'michael@example.com', progress: 20, emp_number: '247', ratings: 1.5 },
      { id: 4, name: 'Emily Johnson', age: 25, email: 'emily@example.com', progress: 80, emp_number: '248', ratings: 2.25 },
      { id: 5, name: 'James Brown', age: 32, email: 'james@example.com', progress: 97, emp_number: '249', ratings: 3.58 },
      { id: 6, name: 'John Doe', age: 30, email: 'john@example.com', progress: 53, emp_number: '250', ratings: 3.50 },
      { id: 7, name: 'Jane Doe', age: 28, email: 'jane@example.com', progress: 91, emp_number: '251', ratings: 4 },
      { id: 8, name: 'Michael Smith', age: 35, email: 'michael@example.com', progress: 63, emp_number: '252', ratings: 4.5 },
      { id: 9, name: 'Emily Johnson', age: 25, email: 'emily@example.com', progress: 25, emp_number: '253', ratings: 4.85 },
      { id: 10, name: 'James Brown', age: 32, email: 'james@example.com', progress: 13, emp_number: '254', ratings: 5 }
    ],
    permissions: {
      searchVisibility: true,
      exportToCsvVisibility: true,
      filterTableHeadersVisibility: true,
      filterBtnTableContentVisibility: true,
      showcaseActionButtons: ['edit', 'delete']
    },
    dependentKeys: {
      progressColumn: 'progress',
      progressBarType: 'bar',
      ratingsColumn: 'ratings',
      filterColumn: 'name',
      maxRating: 5,
      editSaveActionButtonBgColor: '#007bff3b',
      deleteActionButtonBgColor: '#ff73003b',
      closeActionButtonBgColor: '#ff73003b'
    },
    extras: {
      uncheckAllStatus: false,
      dropdownButtonText: 'Table Columns',
      filterBoxArrowStatus: true
    }
  },
  status: 200,
  message: "Fetched Successfully!"
};

or you can try it with json files importing in your service file as well:
Load Table Data JSON Link
Edit Table Data JSON Link
Delete Table Data JSON Link
& modify your Table Data Service file in this way: Delete Table Data JSON Link

Properties

Property	Type	Description
headers	Arr of Obj	"id", "name" & "checked" are mandatory fields required to showcase a table heading
entries	Arr of Obj	Fields name should be exactly same to "header.name" value, to make table in sync
permissions	Object	It contains parent properties mostly for visibility - Show/Hide
dependentKeys	Object	It contains properties mostly dependent upon "permissions" properties
extras	Object	It contains extra properties to update/handle

Properties - Elaborated & Its dependencies on each other:

permissions.searchVisibility:
Show/Hide Search functionality on the top of the table.
Dependent Properties: No
permissions.exportToCsvVisibility:
Show/Hide export to csv button.
Dependent Properties: No
permissions.filterTableHeadersVisibility:
Show/Hide filter for header button.
Dependent Property 1: "extras.dropdownButtonText"(Optional) - To update Dropdown Button text, otherwise default - "Table Columns"
Dependent Property 2: "extras.uncheckAllStatus" - To maintain uncheck All status in overall Table for headers dropdown.
permissions.filterBtnTableContentVisibility:
Show/Hide filter icon for column wise filteration.
Dependent Properties: "dependentKeys.filterColumn" - To add column wise filter functionality to the table & mention particular field name from "entries" - Array of Object, likewise - "name".
permissions.showcaseActionButtons:
Mention 'edit' to enable edit functionality & 'delete' to enable delete button in Array.
Dependent Properties: "dependentKeys.editSaveActionButtonBgColor", "dependentKeys.deleteActionButtonBgColor" & "dependentKeys.closeActionButtonBgColor"(optionals) - To add background colors to button, by default transparent.
dependentKeys.progressColumn:
Mention column/property - exact field from "entries", to enable progressbar to particular column/field. It should be numeric value.
Dependent Properties: "dependentKeys.progressBarType" - "bar" or "circle" to represent in such form.
dependentKeys.ratingsColumn:
Mention column/property - exact field from "entries", to enable ratings to particular column/field (Gained ratings). It should be numeric value.
Dependent Properties: "dependentKeys.maxRating" - Maximum Stars to represent.
extras.filterBoxArrowStatus:
Show/Minimize Filter box at the top of the table, on load.
Dependent Properties: No

Author

You can contact me via. mail for any modiciations/updations for this package.
Suraj Motwani - Email: suraj.motwani1306@gmail.com

License

Dynamic Datatable SM is available under the MIT license. See the LICENSE file for more info.
